2. Correctlyinstallone12Volt(A23)batteryinthebatteryholder.

3. Closethebatterycover.

Maintenance

WARNING: Disconnectpowerbeforeattemptinganymaintenance

orcleaningtoreducetheriskofre,electricshockordamageto

persons.

Required Tools: Phillips#2screwdriver,Slotscrewdriver

Approximatetime:15minutestochangeupperandlowerlightbulbs.

Light Bulb Replacement

Allowatleastve(5)minutesforlightbulbstocooloffbeforetouching

bulbstoavoidaccidentalburningofskin.Lightbulbsneedtobe

replacedwhenyounoticeadarksectionoftheameorwhenthe

clarityanddetailofthelogexteriordisappears.Therearefour(4)

bulbsunderthelogsetwhichgeneratetheamesandembersand

two(2)bulbsup,inbehindthegrillthatilluminatetheinteriorofthe

replace.

To open the light bulb area:

1. Removethetrimbyturningtheretaining

fasteners counterclockwise 1/4 turn until

thetrimreleasesfromthereboxusinga

slottedscrewdriver(Figure7).

2. Holdtheglassinplacewhileremovingthe

retaining clip from the upper center of the

rebox(Figure8A,B).

3. Liftglassoutandstoreinasafeplace.

Lower Light Bulb Requirements

Quantityoffour(4)clearchandelierorcandelabrabulbswithanE-12

(small)socketbase,60Wattrating.

To replace the bottom light bulbs:

1. Liftupthefrontedgeoftheloguntilitclearsthefronttabs.Pullout

Figure 7
