8
Wiring Diagram
DFI2309 MOD C to D
Remote
Control
Receiver
Blower
Flicker Motor
Lamp holders
Cutout
Power Cord
Terminal Block
Main On/Off/On
Switch
Low Heat Switch
High
Heat Switch
Heater Elements
Terminal Block
