11
Power Cord
WARNING: Install the power cord
so that it is stored or secured to avoid
tripping or snagging and to reduce the
risk of re, electric shock, or injury to
persons.
WARNING: This replace is
for use on a 120V circuit and has a
grounding plug that looks like the plug
in Figure 1. Make sure the plug is
connected to an outlet having the same
conguration as the plug. No adapter
should be used with this product.
WARNING: Do not use this
replace with an extension cord. Plug
the cord directly into an ap propriate
wall receptacle.
Electrical
Removing Power Cord for
Hardwire Installation
To remove the power cord:
1. Locate the power cord on the back
of the fireplace. Remove 2 screws
and slide the electrical box back.
2. Unscrew the 2 wire connectors.
3. Cut the green (ground wire) leaving
enough length to reuse the wire.
4. Replace assembly with the hardwire
cover (included).
Figure 1
