12 Device Information
Device information for brine-to-water heat pumps (heating only)
1 Type and order code SI 5MS SI 7MS SI 9MS SI 11MS SI 14MS
2Design
2.1 Degree of protection according to EN 60 529 IP20 IP20 IP20 IP20 IP20
2.2 Installation location Indoors Indoors Indoors Indoors Indoors
3 Performance data
3.1 Operating temperature limits:
Heating water flow °C Up to 55 Up to 55 Up to 55 Up to 55 Up to 55
Brine (heat source) °C -5 to +25 -5 to +25 -5 to +25 -5 to +25 -5 to +25
Antifreeze
Monoethyl-
ene glycol
Monoethyl-
ene glycol
Monoethyl-
ene glycol
Monoethyl-
ene glycol
Monoethyl-
ene glycol
Minimum brine concentration (-13 °C freezing temperature) 25% 25% 25% 25% 25%
3.2 Temperature spread of heating water (flow/return flow) at B0 / W35K 9.4 9.1 10.5 9.5 9.6
3.3 Heat output / COP at B-5 / W55
1
kW / ---
1. This data indicates the size and capacity of the system. For an analysis of the economic and energy efficiency of the system, both the bivalence point and the regulation should
also be taken into consideration. The specified values, e.g. B10 / W55, have the following meaning: Heat source temperature 10 °C and heating water flow temperature 55 °C.
4.0 / 2.0 5.4 / 2.1 7.6 / 2.1 9.4 / 2.0 12.3 / 2.1
at B0 / W50
1
kW / ---
4..8 / 2.7 6.2 / 2.7 8.8 / 2.7 10.5 / 2.6 14.2 / 2.8
at B0 / W35
1
kW / ---
4.9 / 3.9 6.4 / 3.8 9.2 / 4.0 11.0 / 4.0 14.5 / 4.0
3.4 Sound power level dB(A) 54 55 56 56 56
3.5 Heating water flow with an internal pressure differential of m
³
/h / Pa
0.45 / 1900 0.6 / 3300 0.75 / 2300 1.0 / 4100 1.3 / 4800
3.6 Brine throughput with an internal pressure differential
(heat source) of m³/h / Pa
1.2 / 16000 1.7 / 29500 2.3 / 25000 3.0 / 24000 3.5 / 20000
3.7 Refrigerant; total filling weight Type / kg R407C / 0.9 R407C / 0.9 R407C / 1.25 R407C / 1.25 R407C / 1.5
4 Dimensions, connections and weight
4.1 Device dimensions without connections
2
H x W x L mm
2. Note that additional space is required for pipe connections, operation and maintenance.
800 × 600 ×
450
800 × 600 ×
450
800 × 600 ×
450
800 × 600 ×
450
800 × 600 ×
450
4.2 Device connections to heating system Inch
R 1¼" exter-
nal
R 1¼" exter-
nal
R 1¼" exter-
nal
R 1¼" exter-
nal
R 1¼" exter-
nal
4.3 Device connections to heat source Inch
R 1¼" exter-
nal
R 1¼" exter-
nal
R 1¼" exter-
nal
R 1¼" exter-
nal
R 1¼" exter-
nal
4.4 Weight of the transportable unit(s) incl. packing kg 95 98 104 108 120
5 Electrical Connection
5.1 Nominal voltage; fuse protection V / A 230 / 16 230 / 16 230 / 20 230 / 25 230 / 32
5.2 Nominal power consumption
1
B0 W35 kW
1.25 1.68 2.32 2.75 3.62
5.3 Starting current with soft starter A 24 26 38 38 50
5.4 Nominal current B0 W35 / cos ϕ A / --- 6.8 / 0.8 9.1 / 0.8 12.6 / 0.8 15.0 / 0.8 19.7 / 0.8
6 Complies with the European safety regulations
3
3. See CE declaration of conformity
3 3 3 3
7 Additional model features
7.1 Water in device protected against freezing
4
4. The heat circulating pump and the heat pump controller must always be ready for operation.
No No No No No
7.2 Performance levels 11111
7.3 Controller internal/external Internal Internal Internal Internal Internal
