Dimplex VCX1525 - Assembly PART Pictures

12 www.dimplex.com
ASSEMBLY PART PICTURES
Rear Flame Panel
Flame Rod & Left
Bushing & Bracket
Terminal Block
High Temperature
Cutout
Blower Motor
Heater Assembly
Left Element
Connections
Power Cord Connec-
tion (hidden behind
blower Motor)
Dimmer -
Potentiometer Con-
trol & Dial
Thermostat Control
Dial
Heater On/Off
Switch
Main Power - On/
Off/Remote Switch
Remote Receiver
Board
Right Element
Connections
Dimmer Control
Board (Beneath
Heater in front of
remote receiver)
Interior View with Rear Flame Panel Still Attached to the Chassis
Interior View with Rear Flame Panel Detached from the Chassis
Flicker Motor
