13
Heater Assembly
High Temperature
Cutout
Blower Motor
Elements
Remote Control Receiver Board
“L” - Connects to Remote side of Main Power
Switch
Switch Output - Connects to On side of Main
Power Switch
- “Piggy Back” Connects to High
Temperature Thermal Cutout
Switch Output - Connects to Upper Light Bulb
- “Piggy Back” Terminal Block and
Blower Motor
To Next Page
