Dimplex VCX1525 - Remote Control Battery Safety; Unauthorized Modifications Advisory; FCC Compliance Information

6 www.dimplex.com
WIRING DIAGRAM
JUNCTION
BOX
WIRE ENCAPSULATING
HEAT SLEEVE COMPLIANT
TO UL 1026 STANDARD AND
RATED AT 200°C MINIMUM
R/C
HEAT ON
HEAT OFF
REMOTE
OFF
MANUAL
1
2
3
WIRE ENCAPSULATING
HEAT SLEEVE COMPLIANT
TO UL 1026 STANDARD AND
RATED AT 200°C MINIMUM
BLOWER MOTOR
2
1
LIGHT BULB
LIGHT BULB
FLICKER
MOTOR
FLICKER MOTOR
WIRE HARNESS
TERMINAL
BLOCK
CAPACITOR
INTEGRAL ON-OFF
REMOTE CONTROL
N
L
LIGHT BULB
THERMOSTAT
HEATING ELEMENT
THERMO CUTOUT
