Icon Function Description
A Power
Press to turn unit O󰀨 or On.
• Unit O󰀨
Press to turn everything O󰀨. Press again to turn unit On with previous settings.
• Unit On
Press to turn unit On with previous settings.
- If the ame e󰀨ect was On, the ame will turn on and the previous heat setting
will be activated (On or O󰀨). Display will show current heater temperature
setting and after 2 sec displays the room temperature.
- [remote only] If the ame e󰀨ect was O󰀨, the previous heat setting will be
activated (On or O󰀨).
- [panel only] If the ame e󰀨ect was O󰀨, the ame will turn on and the previous
heat setting will be activated (On or O󰀨)
B Heat
• Heat On
Press to turn heat On (indicated by 1 short beep). Display will show current
heater temperature setting and after 2 sec displays room temperature. Use the
Temp icon to change the heater temperature setting.
• Heat O󰀨
Press to turn heat O󰀨 (indicated by 1 short beep).
NOTE: After the heater is switched o󰀨, the fan will continue on for 60 seconds before turning
o󰀨.
C Temperature
Press multiple times to raise the heater temperature in 1
o
F (1
o
C) increments.
Display will show current temperature. Temperature range is 62
o
-78
o
F (17
o
-26
o
C).
This feature is active whenever the heat is enabled.
Disable Heat
Using the manual controls, press the Heat and Temp buttons at the same time
and hold for 2 second to disable the heater. Press and hold again for 2 seconds to
enable the heater.
When the heater is disabled, "--" will display when Temp button is pressed. The
remainder of the unit's controls will operate in the same fashion.
o
C /
o
F
Temp
The display can show the temperature reading in either
o
C or
o
F. To change the
display, press and hold the Temp and Flame Speeds buttons on the unit.
D Flame Speed
Press multiple times to toggle through ame speeds (minimum, medium,
maximum). Display will show current speed number (F1, F2, F3 respectively).
E
Color
Themes
Press multiple times to change the media and ame base colors. This feature is
active only when the ame e󰀨ect is On. Display will show theme (t0, t1, t2, etc.)
XHD28L, XHD26L or XHD23L (Log Unit) themes:
• Theme t0 - no ame
• Theme t1 - Natural (ame base o󰀨)
• Theme t2 - Red Highlights (ame base red/orange)
• Theme t3 - Blue Highlights (ame base blue)
XHD28G, XHD26G or XHD23G (Media Unit) themes:
• Theme t0 - Midnight Mode
• Theme t1 - Media White
• Theme t2 - Media red/orange ickering
• Theme t3 - Media blue ickering.
• Theme t4 - Media Purple
• Theme t5 - Media Green
• Theme to - Prism Mode (To choose a custom color, press Brightness icon. Press
again to return to Prism Mode)
