Dimplex XLF50 User Manual

11
Electrical
120V Installation - Direct
Wire
CAUTION: Use the appropriate
To 120V direct wire:
to the live wire from the power
unit to the neutral wire from the
unit to the ground wire from the
power supply with a wire nut
and do not protrude past the
120V Installation - Wall
Switch
!
NOTE:
rated for a minimum of
CAUTION: Use the appropriate
To wire through a wall switch:
to the live wire from the main
unit to the neutral wire from the
unit to the ground wire from the
power supply with a wire nut
Fireplace Installation

Dimplex XLF50 Specifications

General

Type	Electric Fireplace
Width	50 inches
Voltage	120 V
Wattage	1500 W
Remote Control	Yes
Thermostat	Yes
Installation	Wall-mounted
Dimensions	50 x 20 x 6 inches
