Dimplex XLF50 User Manual

13
Figure 8
240V Installations
CAUTION: Use the appropriate
To 240V direct wire:
unit to the L1 wire from the
unit to the L2 wire from the
unit to the neutral wire from the
unit to the ground wire from the
power supply with a wire nut
and do not protrude past the
Fireplace Installation

Dimplex XLF50 Specifications

General

Type	Electric Fireplace
Width	50 inches
Voltage	120 V
Wattage	1500 W
Remote Control	Yes
Thermostat	Yes
Installation	Wall-mounted
Dimensions	50 x 20 x 6 inches
