14 www.dimplex.com
or other marks, the glass
can be cleaned with a damp
cloth. Ensure that the glass
has completely dried before
installation.
4. Carefully secure the suction cup
to the partially reective glass,
reective side out, and place
into the openings on either side
of the unit.
5. Tip the glass into the unit and
using the removed screws
secure the glass into the unit
with the provided bracket
(Figure 9). Remove the
suction cup.
Fireplace Installation (continued)
6. Evenly space the large media
in the media tray along the back
of the media tray (for optimum
media effect), then carefully
pour and evenly distribute
the smaller media into the
Media Tray.
7. Carefully place the front glass
into the lip located at the bottom
of the opening of the rebox.
8. Tip the front glass into the
unit and secure using the
provided screws and Allen key
(Figure 10).
Figure 9
