C-3 Wheel reduction gears oil -
Check
1 Set the vehicle in the parking position.
Turn the reduction gear cap in the
horizontal position 2.
2 Remove the cap. The oil level is correct
when the oil flows out through the filler
hole.
3 If necessary, top up with oil (photo) 2 to
the correct level.
4 Refit the cap.
5 Repeat this operation for each wheel.
C-4 Steering elements -
Lubrication
1 Lubricate the wheels rotation pins 1 by
injecting grease in the grease nipples
provided for the purpose. Remove the
excess grease.
2 Lubricate the ball joint 2 injecting grease
in the grease nipples provided for the
purpose. Remove the excess grease.
