DINGLI JCPT0407 User Manual

10
OPERATOR’S MANUAL with Maintenance Information
Specifications
JCPT0307
Height, working maximum
(indoor use)
5.0 m
Maximum hydraulic pressure
(functions)
180bar
Height, platform maximum
(indoor use )
Height, working maximum
3.0 m
System voltage 24V/10A
Driving wheels
Φ230×80mm
(outdoor use)
4.5 m
Front wheels Φ152mm
Height, platform maximum
(outdoor use )
Height, stowed maximum
Rails up
Height, stowed maximum
Rails lowered
2.5 m
1.86 m
1.41m
Airborne noise emissions <70 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m / s
2
Maximum slope rating ,
Width
0.76 m
Stowed position
25%
Length, platform retracted
1.15 m
Maximum side slope rating
25%
Stowed position
Length, platform extended
1.7 m
Platform dimensions
Platform length x width
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope
X-1.5
,Y-2
Platform extension length
0.55 m
° °
Drive speeds
Maximum load capacity
240 kg
Stowed, maximum 4.0 km/h
Maximum wind speed
(indoor use)
Maximum wind speed
(outdoor use)
0 m/s
12.5 m/s
Platform raised, maximum
0.5 km/h
Floor loading information
Tire load, maximum 320kg
Wheelbase
0.98 m
Turning radius (outside)
1.1m
Tire contact pressure
8.0Kg/cm
2
784kPa
Occupied floor pressure
908Kg/m
2
Turning radius (inside)
0
Ground clearance
5cm
Weight
554kg
Machine weights vary with option configurations
Power source
2 Batteries , 12V 55AH
Controls
Proportional
AC outlet in platform
Standard
8.9kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations.
It should be used only with adequate safety
factors.
Continuous improvement of our products is a
our policy. Product specifications are subject
to change without notice or obligation.
1.15 x 0.7 m

DINGLI JCPT0407 Specifications

General

Brand	DINGLI
Model	JCPT0407
Category	Scissor Lifts
Language	English
