DINGLI JCPT0407 User Manual

18
OPERATOR’S MANUAL with Maintenance Information
Function Tests
1 Select a test area that is firm, level and
free of obstruction.
2 Be sure the battery pack is connected.
At the Ground Controls
3 Pull out the platform and ground red
Emergency Stop buttons to the on
position.
4 Turn the key switch to ground control.
5 Observe the diagnostic LED readout on
the ECU window.
⊙ Result: The LED should
look like the picture at
right.
Test Emergency Stop
6 Push in the ground red Emergency Stop
button to the off position.
⊙ Result: No functions should operate.
7 Pull out the red Emergency Stop button to
the on position.
Test Up/Down Functions
A buzzer with different sound frequency is
controlled in central system. The descent
alarm sounds at 60 beeps per minute. The
alarm that goes off when the machine is not
level sounds at 150 beeps per minute. An
optional automotive-style horn is also
available.
8 Turn the key switch to off or platform
position.
9 Move up and hold the platform up / down
switch.
⊙ Result: No function should operate.
10 Turn the key switch to ground control
position.
11 Move up and hold the platform up / down
switch.
⊙ Result: The platform should raise.
12 Move down and hold the platform up /
down switch.
⊙ Result: The platform should lower then stop
at the height is 1.2 m. The descent alarm
should sound while the platform is lowering.
13 Move down and hold the platform up /
down switch.
⊙ Result: The platform should lower to end.
The descent alarm should sound while the
platform is lowering.
Test the Emergency Lowering
14 Activate the up function and raise the
platform approximately 60 cm.
15 Pull the emergency lowering knob.
⊙ Result: The platform should lower. The
descent alarm will not sound.
16 Turn the key switch to platform control.
At the Platform Controls
Test Emergency Stop
17 Push in the platform red Emergency Stop
button to the off position.
⊙ Result: No functions should operate.
18 Pull the red Emergency Stop button out to
the on position.
⊙ Result: The LED indicator light shouldcome
on.
Test the Horn
19 Push the horn button.
⊙ Result: The horn should sound.
Test Function Enable and Up/Down
Functions
20 Do not hold the function enable switch on
the control handle.
21 Slowly move the control handle in the

DINGLI JCPT0407 Specifications

General

Brand	DINGLI
Model	JCPT0407
Category	Scissor Lifts
Language	English
