DINGLI JCPT0407 User Manual

OPERATOR’S MANUAL with Maintenance Information
Parts List
61
Item
Part Number
Description
Qty.
Remark
1
GB/T 818-2000
Screw M4×10
12
2
JCPT5007MQ-113003
Cover plate
1
3
JCPT5007MQ-113004
Cover plate2
1
4
Alarm beacon
1
5
JCPT5007MQ-213100
Chassis
1
6
AAZ8104
Travel switch
1
7
JCPT3707M-00018
Shield sleeve 6
1
8
Shield sleeve 12
1
9
GB/T 70.1-2000
Screw M10×30
8
10
GB/T 97.1-2002
Washer 10
8
11
HX-SHCS 3/8-24x1
Screw SHCS 3/8-24x1
8
12
JCPT5007MQ-213121
Connect seat
2
13
JCPT5007MQ-170102
Ladder
1
14
GB/T 5783-2000
Screw M8×20
4
15
GB/T 818-2000
Screw M6×12
4
16
JCPT5007MQ-113005
Plate
1
17
ECC4T2440450LGBL
Driving motor
1
18
JCPT5007MQ-213310
Wheel
2
19
GB/T 97.1-2002
Washer 12
2
20
GB/T 6182-2000
Nut M12
2
21
JCPT0807-112006
Outer cover
2
22
GB/T 97.1-2002
Washer 4
12
23
GB/T 93-1987
Spring Washer 4
12
24
GB/T 70.1-2000
Screw M4×10
6
25
DC55
Battery
2
26
GB/T 70.3-2000
Screw M6×8
4
27
25’Bi=57N.1PZ
Towline
1
28
GB/T 818-2000
Screw M5×8
4
29
GB/T 97.1-2002
Washer 5
4
30
GB/T 93-1987
Spring Washer
4
