OPERATOR’S MANUAL with Maintenance Information
Specifications
22
Model: JCPT0808HA
Height, working maximum 8 m
Height, platform maximum 6 m
Height, stowed maximum
Rails up
2.23 m
Height, stowed maximum
Rails folded
1.87 m
Width 0.83 m
Length, platform retracted 2.48 m
Length, platform extended 3.38 m
Platform dimensions
(length × width)
2.27×0.81 m
Platform extension length 0.9 m
Maximum load capacity 380 kg
Maximum wind speed 12.5 m/s
Wheelbase 1.87 m
Turning radi us (outside) 2.10 m
Turning radi us (inside) 0 m
Ground clearance 10 cm
Ground clearance
Pothole guards deployed
1.9 cm
Weight
（See Serial Label）
Machine weights vary with option configurations
Controls Proportional
AC outlet in platform Standard
Maximum hydraulic pressure
(functions)
240 bar
System voltage 24 V
Tire size Φ381×127 mm
Airborne noise emissions <70 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m/s
Maximum slope rating,
Stowed position
25%
Maximum side slope rating,
Stowed position
25%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope X-1.5°,Y-3°
Drive speeds
Stowed, maximum 3.5 km/h
Platform raised, maximum 0.8 km/h
Floor loading information
Tire load, maximum 1000 kg
Tire contact pressure 11.1 kg/cm
1086.9 kPa
Occupied floor pressure 1339 kg/m
13.1 kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
ade
uate safet
factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
