DINGLI JCPT0807HA - Specifications

OPERATOR’S MANUAL with Maintenance Information
Specifications
21
Model: JCPT0807HA
Height, working maximum 7.8 m
Height, platform maximum 5.8 m
Height, stowed maximum
Rails up
2.15 m
Height, stowed maximum
Rails folded
1.83 m
Width 0.76 m
Length, platform retracted 1.86 m
Length, platform extended 2.76 m
Platform dimensions
(length × width)
1.67×0.74 m
Platform extension length 0.9 m
Maximum load capacity 230 kg
Maximum wind speed 12.5 m/s
Wheelbase 1.36 m
Turning radi us (outside) 1.64 m
Turning radi us (inside) 0 m
Ground clearance 9 cm
Ground clearance
Pothole guards deployed
1.6 cm
Weight
（See Serial Label）
Machine weights vary with option configurations
Controls Proportional
AC outlet in platform Standard
Maximum hydraulic pressure
(functions)
180 bar
System voltage 24 V
Tire size Φ323×100 mm
Airborne noise emissions <70 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m/s
2
Maximum slope rating,
Stowed position
25%
Maximum side slope rating,
Stowed position
25%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope X-1.5°,Y-3°
Drive speeds
Stowed, maximum 4.0 km/h
Platform raised, maximum 0.6 km/h
Floor loading information
Tire load, maximum 710kg
Tire contact pressure 10.4kg/cm
2
1019kPa
Occupied floor pressure 1373kg/m
2
13.5kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
ade
q
uate safet
y
factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
