DINO RXT
F8
Socketoutletonplatform10Aautom.(PK).
F9
ModuleXS2-A03A(PK).
F10
ModuleXA2-A010A(PK).
F11
ModuleXA2-A010A(PK).
F12
ModuleXS2-A010A(PK).
F17
Basketrotation10A(PK).
XA2-A0
Power supply unit
Bus module used for controlling the propo valves and relays and as a connection terminal for
the sensors.
XS2-A0
Signal unit
Bus module used for controlling the relays and as a connection terminal for the sensors.
OK2 CONTROL CENTRE 2
S1
Locking EMERGENCY STOP button.
Stops all other functions except the emergency descent and the sound signal, which remain
operational.
S13
Non-lockingstartbuttonforemergencydescent.
S16
Non-lockingcontrolswitchfor“swingright-left”onthechassiscontrolpanel.
S17
Non-lockingcontrolswitchfor“boomup-down”onthechassiscontrolpanel.
S18
Non-lockingcontrolswitchfor“telescopein-out”onthechassiscontrolpanel.
S19
Non-lockingcontrolswitchfor“articulatedarmsup-down”onthechassiscontrolpanel.
S20
Non-lockingswitchforlevellingoftheplatform.
S30
Retractingthetelescope-button
After the SR3 has tripped, the telescope can be retracted by depressing the button.
Q2
Q2: Switch lock:
Operation is only possible in the same operating position where the lift was started
Position 0 = all electricity switched off
Position 1 = switches on the voltage to the control circuit of the main relay, the normal operating
position.
Position 2 = switches on the engine glowing.
Position 3 = start
H3
Signal light
The alarm display, the reason can be checked on the MDM display on the platform control
panel.
H6
Signal light
The signal light for engine glowing, the light is illuminated as the key switch is turned to position
Glowing.
The light only indicates that the key is in the glowing position, not e.g. how for long the glowing
current has been on.
