Directed Electronics Clifford 20.7X User Manual

13
© 2009 Directed Electronics. All rights reserved.
Menu 2 - Convenience
Menu
Item
Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 One-time Bypass
No Bypass
Bypass
2 Override Pulse Count
1
2 3 4 5
3 Door Open Error chirp*
On
Off
4 Ign-controlled Dome light
On
Off
5 OEM Alarm Disarm w/Aux/
trunk
On
Off
6 OEM Alarm Disarm Output
With Unlock
Before Unlock Remote Start
Only
7 OEM Alarm Disarm Pulses
1
2
8 Aux 1 Output type
Validity
Latch Latch/reset/
ign
Timed Off (5)/2nd
Unlock (6)
9 Aux 1 Linking
No Linking
Link to Lock Link to Unlock Link to Lock/
Unlock
Link to Remote
Start only
10 Aux 2 Output type
Validity
Latch Latch reset/ign Timed Off (5)/2nd
unlock (6)
11 Aux 2 Linking
No Linking
Link to Lock Link to Unlock Link to Lock/
Unlock
Link to Remote
Start only
12 Aux 3 Output type
Validity
Latch Latch reset/ign Timed Off (5)/2nd
unlock (6)
13 Aux 3 Linking
No Linking
Link to Lock Link to Unlock Link to Lock/
Unlock
Smart Key
Control (Link to
Remote Start
Off)*
14 Aux 4 Output Type Validity
Latch Latch reset/ign Timed Off (5)/2nd
Unlock (6)
15 Aux 4 Linking No linking
Link to Lock Link to Unlock Link to Lock/
Unlock
Link to Remote
Start Only
16 Aux/Trunk Output type Validity
Off 2nd unlock
* The H1/6 Violet or the H1/8 Green wire needs to be connected for this feature.
1. One-time Bypass
Off: One-Time Bypass is not available1.
On: the One-Time Bypass feature will defeat Passive Locking once and, if Locked by remote control, 2.
will defeat Comfort Closure and Aux outputs linked to Locking
2. Override Pulse Count
1-5: sets the number of presses (1-5) on the Control Button required to override the alarm system•
3. Door Open Error chirp
On: if the door trigger is active when locking, the horn will emit a honk and a message will be sent 1.
to the 2way remote control as an alert
Off: an active door trigger when locking will not create an alert output 2.
4. Ign-controlled Dome light
On: the dome light output will activate when the ignition is turned off1.
Off: the dome light output will not activate when the ignition is turned off2.
5. OEM Alarm Disarm w/Aux/Trunk (H2/1 wire)
On: the OEM Alarm Disarm wire will pulse as programmed when the Aux/Trunk output is activated1.
Off: the OEM Alarm Disarm wire will not pulse when the Aux/Trunk output is activated2.
6. OEM Alarm Disarm Output (H2/1 wire)
With Unlock: the OEM Alarm Disarm wire will pulse as programmed at the same time as the unlock 1.
