Menu 3 - Remote start
Menu
Item
Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 Transmission Mode
Manual*
Automatic
2 Engine Checking Mode
Virtual Tach
Voltage Off Tachometer
3 Cranking Time
0.6 sec.
0.8 sec. 1.0 sec. 1.2 sec. 1.4 (5)/ 1.6
(6)/ 1.8 (7)
2.0 (8)/ 4.0
(9)
4 Remote Start Runtime
12 min.
24 min. 60 min.
5 Activation Pulse Count
1
2
6 Turbo Mode
No Turbo Mode
On-1 min. On-3 min. On-5 min.
On- 10 min.
7 Timer Mode Runtime
12 min.
3 min. 6 min. 9 min.
8 Flex Relay Function
Ignition 2
Accessory 2 Starter 2
9 Diesel Start Delay
Wait-to Start
input
Timed 15 sec. Timed 30 sec. Timed 45 sec.
10 Accessory during Diesel Start
Delay
On
Off
11 Status 2 Output
Status
Latch Rear
Defogger
Pulse Rear
Defogger
12 Parking Light Output
Constant
Pulsed Off
13 Anti-grind Output
On
Off
14 Tach Mode Starter Release
Normal
Increase Decrease
15 Vehicle Temp Auto Report**
Off
On
16 Remote Start Safelock
Off
On
* The H1/6 Violet or the H1/8 Green wire needs to be connected for this feature.
** Not available on 1-way remote
1. Transmission Mode
Manual: requires ‘Tachometer’ for the Engine Checking Mode, and requires the user to successfully 1.
perform a procedure when parking the vehicle before remote starter will engage
Automatic: uses any of the Engine Checking Modes and does not require any special procedures 2.
when parking
2. Engine Checking Mode
VirtualTach: battery voltage drop/rise during cranking determines when the starter output is released. 1.
During runtime, constant voltage level is monitored to determine if the engine is running
Voltage: starter output during cranking is a programmed duration (Set in Cranking Time). During 2.
runtime, constant voltage level is monitored to determine if the engine is running
Off: starter output during cranking is a programmed duration (Set in Cranking Time). The remote start 3.
will keep the ignition/accessories active for the programmed runtime whether the engine is running
or not
Tachometer: tachometer input signal during cranking and runtime to determine when the starter out-4.
put is released and if the engine is running.
3. Cranking Time
0.6/0.8/1.0/1.2/1.4/1.6/1.8/2.0/4.0 seconds: determines the starter output duration during •
cranking for the ‘Voltage’ and the ‘Off’ Engine Checking Mode options
4. Remote Start Runtime
12/24/60 minutes: sets engine runtime during normal remote start operations•
5. Activation Pulse Count
1/ 2 pulses: sets the number of remote control commands received or Activation Input required to •
