37
© 2006 Directed Electronics
type G: positive (+) multiplex
This system is most commonly found in Ford, Mazda, Chrysler
and GM vehicles. The door lock switch or door key cylinder
may contain either one or two resistors.
SSIINNGGLLEE--RREESSIISSTTOORR TTYYPPEE::
If one resistor is used in the door
lock switch/key cylinder, the wire will pulse (+)12V in one direc-
tion and less than (+)12V when operated in the opposite direction.
TTWWOO--RREESSIISSTTOORR TTYYPPEE::
If two resistors are used in the factory
door lock switch/key cylinder, the switch/key cylinder will read
less than (+)12V in both directions.
DDEETTEERRMMIINNIINNGG TTHHEE PPRROOPPEERR RREESSIISSTTOORR VVAALLUUEESS::
To
determine the resistor values, the door lock switch/key cylinder
must be isolated from the factory door lock system. For testing, use
a calibrated digital multimeter that is set to ohms.
1. Cut the output wire from the door lock switch/key cylinder in half.
2. Test with the meter from the switch side of the cut door lock
switch/key cylinder wire to a reliable constant (+)12V source.
Some good constant (+)12V references are the power input
source to the door lock switch/key cylinder, the ignition switch
note: Please refer to the Door Locking Systems document
on
wwwwww..ddeessiiggnntteecchh--iinnttll..ccoomm
(On-Line Tech Support,
Tech Tips) for complete resistor test procedure and addi-
tional information for multiplexed door locks.
note: To ensure an accurate resistance reading, do not
touch the resistor or leads during testing.
