933.HONDA9 2.10.198.12 2022 Honda HR-V (Smart Key)
©2023 Directed. All rights
Step 10
Pinpoint the loose Violet/Brown MUX wire of the THHON9 T-Harness.
Step 11
Connect the Violet/Brown MUX wire to the Dk. Blue/Black wire labeled RC2 as shown.
Step 12
Place a new tie wrap and ensure all connections are well taped and secure.
IMPORTANT! Ensure that all connections are done properly and taped.
