page 7 of 56ANDIAMO 2.XT (SRC) Hardware Guide - Version 2.1
CHAPTER 1: Overview
Feature Summary
MADI Ports 2 x SC-Socket multi/single-mode (SC/SC)
or
1 x SC-Socket multi/single-mode &
1 x coaxial BNC connector, 75 Ω (BNC/SC)
MADI Formats 56/64 channel, 48k/96k Frame, S/MUX 2/4
AES Ports 16 x AES3 input and output via DSUB-25,
AES59 compliant
Sample Rate Converter 16 x stereo on AES3 inputs (SRC version)
Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz ±12.5%
Analog I/O 32 x channels analog input and output,
balanced via DSUB-25, AES59 compliant
Clock Inputs 1 x Word clock, coaxial BNC,
75 Ω termination switchable,
This input also accepts an AES3 frame (AES11).
Clock Outputs 1 x Word clock, coaxial BNC
USB Port USB 2.0 port for firmware updates and remote
control
Routing Matrix Signal routing on a per channel basis
192x192 routing matrix.
Remote Control Software Remote control via USB, Serial over MADI,
MIDI over MADI or DO.Net
Power Supply This device is equipped with two wide range power
supplies (84 V to 264 V AC / 47 Hz to 63 Hz / safety
class 1)
Applications
ANDIAMO 2.XT (SRC) can be used for conversion, monitoring, recording and
routing of analog and digital signals.
Typical applications include:
• monitoring digital audio
• recording line signals
• redundant recording using both MADI I/Os
• signal routing / distribution (192 x 192 cross points)
• conversion from / to AES to / from MADI
• integration of asynchronous AES signals (SRC Version)
• mixed conversion of AES and analog signals to MADI
• format conversion of MADI signals
• ...
