CHAPTER 4: Operation
SAMPLE
RATE
44.1k
LED green - indicates the base
rate of the audio engine.
(OFF) = base rate is different
from 44.1 kHz
(ON) = base rate of 44.1 kHz
(or multiple of) is used
SAMPLE
RATE
48k
LED green - indicates the base
rate of the audio engine.
(OFF) = base rate is different
from 48 kHz
(ON) = base rate of 48 kHz (or
multiple of) is used
SAMPLE
RATE
2 FS
LED yellow - indicates the scaling
factor of the base rate.
(OFF) = scaling factor is 1 FS
(ON) = scaling factor is 2 FS
SAMPLE
RATE
4 FS
LED white - indicates the scaling
factor of the base rate.
(OFF) = scaling factor is 1 FS
(ON) = scaling factor is 4 FS
