Chapter 1: Overview
Feature Summary
MADI Ports 1 x SC multi-mode connectors *
1 x SFP (empty cage without module)
1 x coaxial BNC connectors
Network 3 x RJ45 Socket (1 Gbit/s),
1 x RJ45 (1 Gbit/s, PoE)
Number of streams 32
Number of channels 64 @ 1 FS, 32 @ 2 FS, 16 @ 4 FS
Network Standards Dante, AES67
Modes Switched or Redundancy
Remote Dante Controller, EXBOX.MD Remote
MADI Formats 56/64 channel, 48k/96k Frame, S/MUX 2/4
Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz +/-
12.5%
Power Supply external,
2 x Hirose connector (9-24 V)
1 x PoE (Power over Ethernet)
* The SC I/O may be ordered as single-mode upon
request.
