CHAPTER 4: Operation
Sample Rate
The base rate (44.1 kHz, 48 kHz) and the scaling
factor (1 FS, 2 FS, 4 FS) is displayed by four leds at
the front panel.
NOTE
At higher sample rates the number of audio channels
is reduced depending on the integer of the scaling
factor:
• 64 channels at 1 FS
• 32 channels at 2 FS
• 16 channels at 4 FS
