page 32 of 60 EXBOX.MD Manual - Version 1.0
CHAPTER 4: Operation
Input / Output - Network
Four network ports are available for transmission of
audio signals and remote control. The built-in network
switch can be operated in two modes:
• switched - four ports, individual operation
• redundant - two ports, primary & secondary
The switch will be confi gured automatically by
selecting the respective operation mode in Dante
Controller.
With redundant operation each two interfaces
( primary / secondary) are combined into a single
logical port; i.e. port 1 / 3 and port 2 / 4.
NOTE
If redundancy is being used, secondary interfaces
should be connected to a second separate network.
Secondary interfaces cannot communicate with
primary interfaces.
