CHAPTER 5: Remote Control
SYNC
SYNC
PTP
SFP
BNC
SC
PTP
LED RGB - indicates selected clock
source and the lock / sync state of
MADI input, PTP-clock or the internal
clock generator.
(OFF) = no signal lock
(100 % green) = signal lock, in sync,
selected clock source
(blinking red) = signal lock, not in sync
with selected clock
source
(blinking green) = input selected as
clock source and
no signal lock.
Clock
master
Pull-down menu - selection of clock
source
Values:
PTP = PTP clock (Master or Slave)
SFP = MADI SFP input
BNC = MADI BNC input
SC = MADI SC input
INT 44.1 = internal clock generator 44.1 kHz
INT 48 = internal clock generator 48 kHz
Scaling
Factor*
Pull-down menu - selection of scaling
factor of base sample rate
Values: 1 FS, 2 FS, 4 FS
* See „Introduction“ on page 27.
