Dish Antennas - DISH 1000.2 2 - 5
DISH 1000.2
Standard Configuration
• Views 110°, 119°, and 129°.
• Standard Configuration: DP Plus 1000.2 LNBF with three receiver outputs.
• A fourth orbital location can be added using the DPP 1000.2’s LNB I
N port. The
LNB I
N port is disabled when the LNBF is connected to a switch.
• The default output of the receiver ports is 119° on P
ORT 1, 110° on PORT 2, and
129° on P
ORT 3. Note that the output ports do not follow the feed horns; PORT 1
is used for peaking on 119°.
• Any Legacy receivers must be installed with at least one DISH Pro or DP Plus
receiver to provide power to the LNBF.
DP Plus 1000.2 LNBF
