Dish Network DISH 1000.2 - SuperDISH 105 and SuperDISH 121

Dish Antennas - SuperDISH 105 and SuperDISH 121 2 - 10
SuperDISH 105 and SuperDISH 121
• Views 110°, 119°, and 105° or 121°.
• Uses DP34 Switch, DP Plus 44 Switch, or DP Plus 33 Switch.
– A DP Plus 33 Switch can be used for single-cable/dual-tuner receiver installations
with DP Plus Separators.
– A DP Plus 44 Switch can be used for an additional orbital location, or for single-
cable/dual-tuner receiver installations with DP Plus Separators.
– Do not use Legacy LNBFs and switches.
• The following Legacy receivers do not have 105° or 121° support: Models 1000, 3000,
4000, 5000, JVC-DVHS (IRR), and DishPlayer 7100/7200.
• Antenna dimensions: 34.3"W x 24.4"H.
For more information: Getting to Know the SuperDISH Antenna.
SuperDISH 121
SuperDISH 105
