6.1.3. Changing the outlet direction of the machine
Unless otherwise requested in your order, the cabinet is delivered with the disposer’s outlet on
the back of the cabinet. Regarding the cabinet’s locaon in relaon to the drain connecon in
the oor / oor, it is possible to turn the disposer with outlet 90⁰ to the le or to the right. If
necessary, this is done as follows
Open the door, if necessary, remove it.
To avoid injuries when unscrewing the disposer from the connecng ange of the hopper, the
boom of the disposer must be supported by a liing trolley.
Unscrew the six nuts that hold the disposer against the connecng ange of the hopper. Unscrew
the hood 4 nuts with washers and turn it one step clockwise, ghten the hood. For models
510A-520A pull with torque 9.5 Nm and for models 530A-575A pull with 21 Nm. Then turn the
disposer with the outlet to the desired le or right posion.
Check that the seal between the disposer and the hopper connecon ange is correct before
screwing the grinder back on. Tighten the six nuts evenly.
Punch a hole in the side panel to enable the outlet pipe to be connected to the disposer in the
new posion. For models with a motor power below 2.5 kW, the hole diameter should be 63-65
mm. For models with a motor power of 2.5 kW or more, the hole diameter should be 73-76 mm.
There are two small marks on the le and right sides of the outer casing.
Use the upper mark for models with a motor power below 2.5 kW or the lower mark for models
with a motor power of 2.5 kW or more, to center the posion of the new hole.
The original hole for the drain pipe should be covered with a stainless steel plate that is screwed
to the back. This plate can be delivered as an opon by Disperator AB.
