6.2.4. Other orders / installations for which standard EN 1717 does not apply
In cases where standard EN 1717 does not apply (eg countries outside the EU or marine
installaons) it is sll recommended that a vacuum valve (non-return valve), G½” (BSPP), be
installed on top of the lyre-shaped incoming water pipe according to the gure below. The
vacuum valve protects the water pipe against re-sucon in the event of overow. Vacuum valve is
not included in standard delivery but can be ordered as an opon from Disperator.
T h e p i c t u r e a b o v e s h o w s a n e x a m p l e o f t h e l o c a  o n o f a v a c u u m v a l v e a b o v e
a standard installaon of a cabinet.
300
Vacuum valve
Hose with protecve
steel-covered stocking
Incoming water pipe to ushing
nozzle with solenoid valve
and line strainer
