100sx Operator’s Manual Service - 67
50 Hour
Change Air Filter
Change air filter every 50 hours or annually,
whichever occurs first.
To change:
1. Remove air filter cover (2) by removing
fastener (1).
2. Remove fastener (3) and filter (4).
3. Remove pre-cleaner (if equipped) from the
filter.
4. Replace air filter and pre-cleaner.
5. Assemble pre-cleaner to filter.
6. Install seal washer (5) filter, and pre-cleaner into the base.
7. Install cover and secure.
NOTICE: Compressed air or water may
damage filter elements.
t44om015w.eps
1
3
5
2
4
