Specifications - 72 100sx Operator’s Manual
100sx
Operation U.S. Metric
Maximum crowd speed
Forward 92 fpm 28 m/min
Reverse 92 fpm 28 m/min
Vehicle clearance circle 70 in 178 cm
Plow blade sizes
Pull blades (cover depth x mole diameter) 6-12 x .75 in 152-305 x
19 mm
Feed blades (tube diameter x cover depth (bend radius)) .375 x 6-12
(1) in
9 x 152-305
(25) mm
Operating weight 720 lb 327 kg
Power U.S. Metric
Engine: Briggs & Stratton
®
2100 Series gasoline engine
Cooling medium: air
Number of cylinders: one
Displacement
25.6 in
3
20.98 cm
3
Bore 3.54 in 90 mm
Stroke 2.6 in 66 mm
Engine manufacturer’s gross power rating @ 3600 rpm 13.5 hp 10.1 kW
*Maximum governed speed as installed (no load) 3400 rpm 3400 rpm
Flywheel power @3400 rpm (full load) 10.2 hp 7.5 kW
Fuel consumption @ 3600 rpm 0.89 gph 3.4 L/h
**Maximum tilt angle 20° 20°
*All warranty is void is engine is run above maximum governed speed as installed (no load).
**Exceeding these operating angles will cause engine damage. This DOES NOT imply machine is stable to maximum angle of safe
engine operation.
