FX30/FXT30 Operator’s Manual Specifications - 139
FX30-800
Engine U.S. Metric
Kubota D1105-E3B, diesel, EPA Tier 4 emissions
Cooling medium liquid
Injection indirect
Aspiration natural
Number of cylinders 3
Displacement
68.6 in
3
1.12 L
Bore 3.07 in 78 mm
Stroke 3.09 in 78.5 mm
Engine manufacturer’s gross power rating (per SAE J1995) 24.8 hp 18.5 kW
Estimated net power rating (per SAE 1349) 23.5 hp 17.5 kW
Rated engine speed 3000 rpm 3000 rpm
Hydraulic system U.S. Metric
Pressure 2500 psi 172 bar
Drive type engine-driven gear pump
Tank lift cylinder size (2) 3 in 76 mm
Maximum tilt angle 45° 45°
Battery
SAE res. cap. 110 min; SAE cold crank @ 0°F (-18°C) 800A, 12V
Vacuum system U.S. Metric
Drive type belt
2-Lobe blower displacement 576 cfm
16.3 m
3
/min
Maximum vacuum 15 in Hg 405 mm Hg
Filter type washable polyester
Filter area
100 ft
2
9.3 m
2
Suction hose size 3 in 76 mm
