FX30/FXT30 Operator’s Manual Transport - 63
Lift
Tank
Use crane capable of supporting the weight shown below.
Use top lift point (1) as shown. Use end lift point (2) to
drain tank if machine is disabled.
Haul
Inspect Trailer
• Check hitch for wear and cracks. Lubricate if needed.
• Check battery for 12V charge.
• Inspect lights for cleanliness and correct operation. Inspect reflectors and replace if needed.
• Check tire pressure. Check lug nut torque with a torque wrench.
• Ensure trailer brakes are adjusted to come on in synchronization with tow vehicle brakes.
• Check ramps (if equipped) and trailer bed for cracks.
500 gallon 2000 lb (907 kg)
800 gallon 2500 lb ( kg) kg
NOTICE:
• Relieve pressure in tank before storing or
transporting.
• Only lift empty water or spoils tanks.
• Do not lift tank by vacuum boom, if installed.
Crushing weight could cause death or serious injury. Stay
away.
275-326
To help avoid injury:
• Do not haul or move trailer unless tank is fully lowered and horizontal. Damage to machine or injury
to personnel could occur.
• Do not haul or move trailer unless optional vacuum boom is secured by boom latch. Damage to
machine or injury to personnel could occur.
• Do not travel on roads with reducer or any other fitting installed on tank outlet valve. Fitting will
extend beyond the rear impact guard and will not be legal for operation on roadways.
