FX30/FXT30 Operator’s Manual Controls - 35
Power Pack
Gauges and Indicators
1. Hourmeter
2. Engine oil pressure indicator
3. Engine coolant temperature indicator
4. Cold start wait indicator
5. Not used
6. Battery disconnect switch *
7. Water pressure gauge
8. Fuel gauge
* FXT30 units and FX30 units from CMWFX30XLE0002054
Item Description Notes
1. Hourmeter Displays engine operating
time.
Hourmeter runs when engine is
running.
Use these times to schedule service.
7
6
8
j33om001w.eps
