DITEC CUBIC6 Installation And Maintenance Manual

10
IP1812EN • 2012-07-10
6.8 Installation with CUBIC6TIG
Fix the plate [A], then insert, x and lubricate the gears [B], [C] and [D]. Position the sphere [E] as shown in
the gure.
A
E
C
D
B
6.9 CUBIC6FM-CUBIC6FMTI installation
It is possible to limit the travel of the wing by means of magnetic limit switches.
Choose and install the magnetic limit switches as indicated in the relative manual.
Make the electrical connections as shown in the control panel.
WARNING: the magnetic limit switches cannot interrupt the power supply to the motor.
