11
IP1812EN • 2012-07-10
7. ELECTRICAL CONNECTIONS
Before connecting the power supply, make sure the plate data correspond to that of the mains power supply.
An omnipolar disconnection switch with minimum contact gaps of 3 mm must be included in the mains supply.
Check that upstream of the electrical installation there is an adequate residual current circuit breaker and a
suitable overcurrent cutout.
WARNING: the electrical connections for the extension of the motor cables must be made on the outside of the
foundation casing in an appropriate junction box (not supplied).
In the CUBIC6 gearmotors, the blue wire corresponds to the common contact of the motor phases, and must
be connected to the W or Z terminals of the control panel.
The CUBIC6 gearmotor can be connected to the E2 and LOGICM control panels.
The CUBIC6H and CUBIC6VH gearmotors can be connected to the VIVAH control panel.
The electrical connections and the start-up of the gearmotors are shown in the installation manuals of the E2,
LOGICM and VIVAH control panels.
8. ROUTINE MAINTENANCE PLAN
Perform the following operations and checks every 6 months according to intensity of use of the automation.
Without 230 V~ power supply and batteries if present:
- Lubricate the levers of the gearmotor.
- Lubricate the rotation pivot of the gate leaf.
- Lubricate the gate leaf hinges.
- Check the good conditions of the electric connection.
- Check that the xing screws of the gearmotor are rmly tightened.
- Clean the inside of the cases and check that drain is not clogged.
- Check the value of the capacity of the motor condenser.
Reconnect the 230 V~ power supply and batteries if present:
- Check the power adjustment.
- Check the good operation of all command and safety functions (photocells).
- Check the good operation of the release system.
NOTE: For spare parts, see the spares price list.
