8. START-UP
WARNING The operations in point 3 are performed without safety devices.
The trimmer can only be adjusted with the automation idle.
1- Make a jumper for the N.C. safety contacts.
2- Set DIP4=OFF.
3- Switch on and check that the automation is operating correctly with subsequent opening and closing
commands.
Check that the limit switches are activated.
NOTE: if the direction of rotation of the motor is incorrect for the desired direction of the automation, swap
the L2 and L3 phases.
4- Connect the safety devices (removing the relative jumpers) and check they work correctly.
WARNING: check that the working forces exerted by the door wings are compliant with EN12453-EN12445
regulations.
5- If required, activate automatic closing using command 1-2 and adjust the time using the TC trimmer.
6- If required, activate partial opening using command 1-20 and adjust the time using the RP trimmer.
7- If required, connect the radio receiver to the relative AUX connector, program the transmitters as described
in the relative manual and check that all elements function correctly.
8- Connect any other accessories and check they operate correctly.
9- Once the start-up and check procedures are completed, close the container.
i
NOTE: in the event of servicing or if the control panel is to be replaced, repeat the start-up procedure.
