6. OUTPUTS AND ACCESSORIES
Output Value - Accessories Description
01
+
-
24 V= / 0,5 A
Accessories power supply. Power suppl\ output for external ac-
cessories, includinJ automation status lamp.
1 11
24 V= / 3 W
Open automation lamp. Onl\ with the 0-11 limit switch (N.C.) con-
nected and DIP3B=OFF the liJht switches off when the automation
is closed.
1
12
24 V= / 3 W
Closed automation lamp. Onl\ with the 0-12 limit switch (N.C.)
connected and DIP3B=OFF the liJht switches off when the automa-
tion is open.
1
13
24 V= / 3 W
Open automation lamp. The liJht switches off when the automation
is closed.
0
15 12 V= / 15 W
Electric lock. Activated upon ever\ openinJ command.
W
N
LAMP
230 V~ / 100 W
Flashing light. Activated durinJ openinJ and closinJ operations.
X
L
230 V~ / 100 W
Courtesy light. In 1 motor mode onl\ (with DIP3B=OFF and no motor
connected to terminals X-=-Y), an external courtes\ liJht that turns
on for 180 s with ever\ openinJ (total or partial), step-b\-step and
closinJ command can be connected.
AUX
The control panel has one housinJ for pluJ-in cards such as a radio
receiver t\pe, maJnetic loops, etc.
PluJ-in card operatinJ is selected usinJ DIP1A.
WARNING: the plug-in cards must be inserted and removed with the
power supply disconnected.
COM
BIXMR2
The storaJe module allows remote controls to be stored.
If the control panel is replaced, the BIXMR2 storaJe module beinJ
used can be inserted in the new control panel.
WARNING: the storage module must be inserted and removed with
the power supply disconnected.
