The programmes P01 - P07 are pre-programmed TENS programmes for transcutaneous
electric nerve stimulation. The programmes U1 - U5 are adjustable TENS programmes.
The respective programme cycles run automatically one after the other and enhance the
effectiveness of the stimulation on the treated muscle or pain region.
(min. = minutes, Hz = vibrations per second, µs = pulse duration in microseconds)
Each programme has an application time of 30 minutes. The corresponding wave forms,
frequencies and pulse durations of the programmes can be found in the programme
overview provided above.
APPLICATION PROGRAMMES
The values shown in the table are factory preset and can be set in the following ranges:
Application time: adjustable from 5 to 90 Minuten
Frequency in Hz: 150 Hz
Pulse duration in
adjustable from 2 to
adjustable fromµs: 50 to 350 µs
Pro-
gram.
Wave form
Applicat.
time
Frequency Hz
Pulse duration µs
P01
continuous
30 min.
1 Hz
50 µs
P02
continuous
30 min.
8 Hz
200 µs
P03
continuous
30 min.
80 Hz
80 µs
P04
Han
30 min.
100 Hz
2 Hz
150 µs
200 µs
P05
Amplitude modulated
30 min.
80 Hz
200 / 330 µs
P06
Pulse duration modulated
30 min.
80 Hz
110-180 µs
P07
Pulse duration modulated
30 min.
2 Hz
150-200 µs
13.0 TENS application programmes
13.1 Pre-programmed TENS application programmes P01 - P07
Pro-
gram.
Wave form
Applicat.
time
Frequency Hz
Factory setting
Pulse duration µs
Factory setting
U1
continuous
30 Min.
100 Hz
100 µs
U2
Amplitude modulated
30 Min.
100 Hz
200 / 330 µs
U3
Pulse duration modulated
30 Min.
80 Hz
150-200 µs
U4
Pulse duration modulated
30 Min.
2-8 Hz
300 µs
U5
Frequency and pulse
duration modulated
30 Min.
2-100 Hz
50-300 µs
13.2 Adjustable TENS application programmes U1 - U5
