D I V E R S I T E C H O M - G F C M
3.5 - Engaging the System:
The control box includes an LCD screen with a Power rotary switch and a Start, Abort Cycle,
Menu/Select & Scroll buttons. A single cleaning cycle is defined as the traveling of the nozzle up and
down the filter.
3.5.1 - LCD Readout
Diversi-Tech
GFCM REV 3.0
You are operating Version 3
The GFCM is resetting itself
"Going Home": Machine is resetting itself by returning to home position
located at the bottom of the mechanism
"2.5A": Amperage reading of the 24V DC Motor operating the mechanism
Ready to Clean
8 Cycle 23-32"
This is the Home Reading
"Ready to Clean": GFCM is ready to clean a dirty filter
"8 Cycle": GFCM will run for 8 cycles
"23-32"": The height range of the dirty filter
Clean UP 2.5A
288 Sec CYC 6/8
The GFCM is in operation
"Clean UP": The nozzle is rotating while moving upwards
"2.5A": Amperage reading of the 24V DC Motor operating the mechanism
"288 Sec": Indicates the remaining time of the cleaning cycle in seconds
"CYC 6/8": GFCM is at its 6th cycle out of 8th
Clean DOWN
2.5A
288 Sec CYC 6/8
The GFCM is in operation
"Clean DOWN": The nozzle is rotating while moving downwards
"2.5A": Amperage reading of the 24V DC Motor operating the mechanism
"288 Sec": Indicates the remaining time of the cleaning cycle in seconds
"CYC 6/8": GFCM is at its 6th cycle out of 8th
Air Pulse system is activated
"Air Jet ON": Air pulse system to clean the cabinet
"045 Sec": Time left to terminate the Air pulse system
Clean Finished
8 Cycle 23-32"
Cycle has ended
"Clean Finished": Cleaning cycles has ended
"8 Cycle": GFCM has cleaned the filter for 8 consecutive cycles
"23-32"": The height range of the dirty filter.
Turn rotary switch ON to power the controller
Push Start to begin cleaning cycle
Push and Hold Menu/Select for one second to enter the Menu
Push < > to scroll over the choices
Push Abort Cycle to skip pre-set number of cycles and complete
current cycle.
