DIVERSITECH GREEN - Specifications

SPECIFICATIONS
SPECIFICATIONS
OVERAL DIMENSIONS
6’ Wide x 6’ Deep x 8’8” High
COMPRESSED AIR
REQUIREMENTS
90 PSI, 1/2" AIR LINE, 80 CFM
ELECTRICAL REQUIREMENTS
208-230V/380V/460V/600V/3P/60Hz
CYCLONE MOTOR
5HP 208-230V/380V/460V/600V, 3-PHASE, 2800RPM or
3400-RPM, 50Hz or 60-Hz
CYCLONE
1400 CFM AT 4" STATIC PRESSURE
ELECTRICAL
ENCLOSURE COMBINES MOTOR STARTER FOR 5HP MOTOR
AND I.C.S. MOTOR
FILTER HEIGHT RANGE
UP TO 32" HIGH
FILTER DIAMETER RANGE
6.5” INNER DIAMETER, 20" MAXIMIUM OUTER DIAMETER
CYCLE TIME
Approx. 4-5 MINUTES
