1592017050 XLR470 GB r1.0 24.05.07.doc XLR470 16/18
17. DEFAULT SETTING VALUES
Label Name Range Default level
REGULATION
Set1
Set point 1 LS1÷US1
-5.0 - - -
Set2
Set point 2 LS2÷US2
3.0 - - -
Hy1
Differential 1 0,1÷25,5 °C / 1÷45°F
2.0 Pr1
Hy2
Differential 2 0,1÷25,5 °C / 1÷45°F
2.0 Pr1
REGULATION – SECTION 1
LS1
Minimum set point1 limit -50,0°C÷SET1 / -58°F÷SET1
-50.0 Pr2
US1
Maximum set point1 limit SET1 ÷ 150°C / SET1 ÷ 302°F
110 Pr2
odS1
Outputs activation delay of sect. 1 at start up 0÷255 min.
0 Pr2
Ac1
Anti-short cycle delay for compressor1 0÷30 min.
1 Pr1
con1
Compressor1 ON time with faulty probe1 0÷255 min.
15 Pr2
coF1
Compressor1 OFF time with faulty probe1 0÷255 min.
15 Pr2
cH1
Kind of action for section 1 cL / Ht
cL Pr2
REGULATION – SECTION 2
LS2
Minimum set point2 limit -50,0°C÷SET2 / -58°F÷SET2
-50.0 Pr2
US2
Maximum set point2 limit SET2 ÷ 150°C / SET2 ÷ 302°F
110 Pr2
odS2
Outputs activation delay of sect. 2 at start up 0÷255 min.
0 Pr2
Ac2
Anti-short cycle delay for compressor2 0÷30 min.
1 Pr1
con2
Compressor2 ON time with faulty probe2 0÷255 min.
15 Pr2
coF2
Compressor2 OFF time with faulty probe2 0÷255 min.
15 Pr2
cH2
Kind of action for section 2 cL / Ht
cL Pr2
DISPLAY
cF
Temperature measurement unit °C / °F
°C Pr2
rES
Resolution (for °C in ÷ de
dE Pr1
Lod1
Bottom display visualization P1 ÷ P4
P1 Pr2
Lod2
Upper display visualization P1 ÷ P4 P3 Pr2
DEFROST
dFS
Relation between defrosts ind; StS; Sti, SE
ind Pr2
tdF1
Kind of defrost section 1 rE, in
rE Pr2
EdF1
Defrost mode, section 1 In, Sd,RTC
in Pr2
SdF1
Set point for Smart Defrost section 1 -30 ÷ +30°C / -22÷+86°F
0 Pr2
dtE1
End defrost temperature section 1 -50,0÷110°C/ -58÷230°F
8.0 Pr2
idF1
Interval between defrosts, section 1 1÷120ore
6 Pr1
MdF1
Maximum duration of defrost, section 1 0÷255 min.
20 Pr1
tPF1
Pre-defrost compressor on time 0÷30 min.
0 Pr2
Fdt1
Dripping time section 1. 1 0÷60 min.
0 Pr2
dPo1
Defrost at power on section . 1 n ÷ y
n Pr2
tdF2
Kind of defrost section 2 rE, in
rE Pr2
EdF2
Defrost mode, section 2: In, Sd, RTC
in Pr2
SdF2
Set point for Smart Defrost section 2 -30 ÷ +30°C / -22÷+86°F
0 Pr2
dtE2
End defrost temperature section 2 -50,0÷110°C/ -58÷230°F
8.0 Pr2
idF2
Interval between defrosts, section 2 1÷120ore
6 Pr1
MdF2
(Maximum) duration of defrost, section 2 0÷255 min.
20 Pr1
tPF2
Pre-defrost compressor 2 on time 0÷30 min.
0 Pr2
Fdt2
Dripping time section 2 0÷60 min.
0 Pr2
dPo2
Defrost at power on section 2 n ÷ y
n Pr2
dFd
Display during defrost rt, it, SEt, dEF, dEG
it Pr2
dAd
Defrost display time out 0÷255 min.
20 Pr2
dSd
Defrost delay 0÷255 min.
0 Pr2
FANS
FnC1
Fans operating mode, section 1 C-n, C-y, O-n, O-y
O-n Pr2
Fnd1
Fans delay after defrost, section 1 0÷255 min.
10 Pr2
FSt1
Fans stop temperature, section 1 -50,0÷110°C/ -58÷230°F
2.0 Pr2
FAP1
Probe for fans P1÷P3
P2 Pr2
FnC2
Fans operating mode, section 2 C-n, C-y, O-n, O-y
O-n Pr2
Fnd2
Fans delay after defrost, section 2 0÷255 min.
0 Pr2
