Label Name Range Default level
FSt2
Fans stop temperature, section 2 -50,0÷110°C/ -58÷230°F
-30.0 Pr2
FAP2
Probe for fans 2 P1÷P3
P4 Pr2
ALARM
ALc1
Temperature alarms configuration, section 1 rE / Ab
Ab Pr2
ALu1
Maximum alarm, section 1 -50,0÷150°C/ -58÷302°F
110 Pr1
ALL1
Minimum alarm, section 1 -50,0÷150°C/ -58÷302°F
-50.0 Pr1
ALd1
Temperature alarm delay, section 1 0÷255 min.
15 Pr2
dAo1
Delay of temp. alarm at start-up, section 1 0 ÷ 23h 50 min.
1.3 Pr2
ALc2
Temp. alarms configuration, section 2 re ÷ Ab
Ab Pr2
ALu2
Maximum alarm, section 2 -50,0÷150°C/ -58÷302°F
110 Pr1
ALL2
Minimum alarm, section 2 -50,0÷150°C/ -58÷302°F
-50.0 Pr1
ALd2
Temperature alarm delay, section 2 0÷255 min.
15 Pr2
dAo2
Delay of temp. alarm at start-up, section 2 0 ÷ 23h 50 min.
1.3 Pr2
AFH
Temperature alarm and fan differential 0,1÷25,5 °C / 1÷45°F
1.0 Pr2
EdA
Alarm delay at the end of defrost 0÷255 min.
20 Pr2
dot
Delay of temp. alarm after closing the door 0÷255 min.
20 Pr2
doA
Open door alarm delay 0÷254 min., nu
15 Pr2
ANALOGUE INPUTS
Pbc
Kind of probe PTC/ntc
ntc Pr2
oFS1
Thermostat1 probe calibration -12,0÷12,0°C / -21÷21°F
0.0 Pr2
oFS2
Evaporator 1 probe calibration -12,0÷12,0°C / -21÷21°F
0.0 Pr2
oFS3
Thermostat 2 probe calibration -12,0÷12,0°C / -21÷21°F
0.0 Pr2
oFS4
Evaporator 2probe calibration -12,0÷12,0°C / -21÷21°F
0.0 Pr2
P2P
Evaporator 1 probe presence n / y
Y Pr2
P3P
Thermostat 2 probe presence n ÷ y
Y Pr2
P4P
Evaporator 2 probe presence n ÷ y
Y Pr2
DIGITAL INPUTS
I1P
Digital input 1 polarity cL÷OP
cL Pr2
i1F
Digital input 1 operating mode
MP1; MP2, MP; EA1; EA2; EAL; bA1; bA2; ,
bAL; dF1; dF2; dEF; oF1; oF2; oFF; ES
EAL Pr2
i2P
Digital input 2 polarity cL÷OP
cL Pr2
i2F
Digital input 2 operating mode
MP1; MP2, MP; EA1; EA2; EAL; bA1; bA2; ,
bAL; dF1; dF2; dEF; oF1; oF2; oFF; ES
EAL Pr2
odc1
Comp. and fan status when open door, sect 1 no, Fan, CPr, F_C
no Pr2
rrd1
Outputs restart after door open alarm, sect. 1 n, y
y Pr2
did1
Time interval delay for digital input alarm, sect. 1 0÷255 min.
5 Pr2
odc2
Comp. status when open door, section 2: no, Fan, CPr, F_C
no Pr2
rrd2
Outputs restart after door open alarm, sect. 2 n, y
y Pr2
did2
Time interval delay for digital input alarm, sect. 2 0÷255 min.
5 Pr2
OTHER
oA6
Auxiliary output configuration
cP1 / cP2 / dF1 / dF2 / Fn1 / Fn2 / Lg1 / Lg2 /
on1 / on2 / db1 / db2 / ALr
ALr Pr2
tbA
Alarm relay silencing n – Y
y Pr1
AoP
Alarm relay polarity cL - oP
cL Pr1
HES1
Temp. increase during the Energy Saving cycle, sect. 1 -30÷30°C / -54÷54°F
0 Pr1
HES2
Temp. increase during the Energy Saving cycle, section 2 -30÷30°C / -54÷54°F
0 Pr1
TIME AND WEEKLY HOLIDAYS (ONLY WITH RTC)
Hur
Current hour 0 ÷ 23 0 Pr1
Min
Current minute 0 ÷ 59 0 Pr1
dAY
Current day Sun ÷ SAt Sun Pr1
Hd1
First weekly holiday Sun ÷ SAt – nu nu Pr1
Hd2
Second weekly holiday Sun ÷ SAt – nu nu Pr1
Hd3
Third weekly holiday Sun ÷ SAt – nu nu Pr1
ENERGY SAVING TIMES (ONLY WITH RTC)
ILE
Energy Saving cycle start during workdays 0 ÷ 23h 50 min. 0 Pr2
dLE
Energy Saving cycle length during workdays 0 ÷ 24h 00 min. 0 Pr2
ISE
Energy Saving cycle start on holidays 0 ÷ 23h 50 min. 0 Pr2
dSE
Energy Saving cycle length on holidays 0 ÷ 24h 00 min. 0 Pr2
