dixell UNIVERSAL XR60CX User Manual

Universal-XR 5/17 UXR01212015_REV1.4mm
Installation and Operating Instructions
Description
Label
Adjustment Range
tC1
tC2
tC3
tC4
tC5
tC6
tC7
Door open – compressor / fan status
ODC
No (0) = No change
FAn (1) = Fan off
CPr (2) = Compressor off
F_C (3) = Compressor & Fan off
0
0
0
0
0
0
0
Defrost relay configuration
OAA
Alr (0) = Alarm;
db (1) = Dead Band;
AUS (2) = Auxiliary;
CP2 (3) = Second compressor output;
liG (4) = Light output;
dF2 (5) = Second defrost output.
dEF (6) =1
st
Defrost output
Fan (7) =Fan output
6
6
6
Auxiliary relay configuration
OAB
Alr (0) = Alarm;
db (1) = Dead Band;
AUS (2) = Auxiliary;
CP2 (3) = Second compressor output;
liG (4) = Light output;
dF2 (5) = Second defrost output.
dEF (6) =1
st
Defrost output
Fan (7) =Fan output
0
0
0
0
7
7
7
Alarm relay polarity
AOP
Cl (0) = [11 -12] closed with alarm
oP (1) = [11 -12] open with alarm
0
0
0
0
0
0
0
Exclude temperature alarm - door open
DOT
0 to 255 min
20
20
20
20
20
20
20
Restart regulation with door open alarm
RRD
n (0) = No
Y (1) = Yes
0
0
0
0
0
0
0
Probe selection for Condenser Alarm
AP2
nP (0) =No Probe selected
P1 (1) =Probe 1
P2 (2) =Probe 2
P3 (3) =Probe3
0
0
0
0
0
0
0
Low temperature alarm of condenser
AL2
-55 to 150°C;
-67 to 302°F
-40°C;
-40°F
-40°C;
-40°F
-40°C;
-40°F
-40°C;
-40°F
-40°C;
-40°F
-40°C;
-40°F
-40°C;
-40°F
High temperature alarm of condenser
AU2
-55 to 150°C;
-67 to 302°F
110°C;
230°F
110°C;
230°F
110°C;
230°F
110°C;
230°F
110°C;
230°F
110°C;
230°F
110°C;
230°F
Differential for temperature condenser
alarm recovery
AH2
0.1 to 25.5°C;
1 to 45°F
5°C;
5°F
5°C;
5°F
5°C;
5°F
5°C;
5°F
5°C;
5°F
5°C;
5°F
5°C;
5°F
Condenser temperature alarm delay
AD2
0 to 254 min, 255 = nU
15
15
15
15
15
15
15
Condenser temperature alarm exclusion at
start up
DA2
0 to 720 min, res. 10 min
90
90
90
90
90
90
90
Compressor off with low temperature alarm
of condenser
BLL
n (0) = No
y (1) = Yes
0
0
0
0
0
0
0
Compressor off with high temperature
alarm of condenser
AC2
n (0) = No
y (1) = Yes
0
0
0
0
0
0
0
Temperature deviation from normal
Set Point during Energy Saving
HES
-30.0 to 30°C;
-54 to 54°F
0°C;
0°F
0°C;
0°F
0°C;
0°F
0°C;
0°F
0°C;
0°F
0°C;
0°F
0°C;
0°F
ON / OFF key enabling
ONF
nU (0) = Disabled
OFF (1) = Enabled
ES (2) = Energy saving
0
0
0
0
0
0
0
Buzzer enabling
BEN
n (0) = Disabled
Y (1) = Enabled
1
1
1
1
1
1
1
Parameter table
PTB
For factory use only
-
-
-
-
-
-
-
Software release number
REL
Read only
-
-
-
-
-
-
-
Evaporator probe temperature
DP2
Read only
-
-
-
-
Third probe temperature
DP3
Read only
-
-
-
-
-
-
-
