dji A2 - Basic Flying Test

©2013 DJI Innovations. All Rights Reserved 25 |
2.6 Basic Flying Test
Carry out the following procedures to complete the basic flight test.
1. Wait the GPS signal to be well
LED
Place the aircraft away from you and others at least 3 meters and wait the ≥6
(about 30 seconds).
or no Red LED
2. Start motors and takeoff aircraft.
LED
Execute CSC to start motors; all sticks back to midpoint as soon as motors start, then push
the throttle stick to take off the aircraft, meanwhile the home point is recorded. NOTE:
36secs after power on; 10secs after ≥6; Motors have been started, auto-record the
position as home point at the first time the throttle stick is raised
(∝)
After the home point is recorded successfully and the distance from aircraft is less than 8m,
LED indicator will blink 6 violet continually. Note: only when GPS signal is good (no Red
LED) LED indicator will blink 6 violet continually.
(6)
3.Operate sticks to control the flying attitude of the aircraft during flight
Transmitter (Mode2)
Aircraft
Operations
Throttle
Stick
Push Throttle sticks to control the aircraft
to elevate and descend. The aircraft can
lock to an altitude when the throttle stick
is at midpoint.
Yaw Stick
Push the yaw stick to rotate the aircraft in
clockwise or counter clockwise direction.
Roll Stick
Push roll stick to control the aircraft left
or right, pitch stick to control forward or
backward.
When both roll and pitch sticks are at
midpoint：
(1) GPS ATTI. Mode: the aircraft will
be stabilized and locked in
horizontal position.
(2) ATTI. Mode: the aircraft will be
stabilized but unlocked in
horizontal position.
Pitch
Stick
