dji A2 - Specifications

©2013 DJI Innovations. All Rights Reserved 37 |
Specifications
General
Built-In Functions
 Built-in Receiver
 Multiple Control Modes
 2-axle Gimbal Supported
 Enhanced FailSafe
 Intelligent Orientation Control
 Dynamical Systems Protection
 PC & Bluetooth Ground Station
 External Receiver Supported
 9 Types of Supported Multi-rotor
 Other DJI Products Supported
 Low Voltage Protection
 4 Configurable Outputs
 Sound Alarm
 Configure Parameters Via Bluetooth
Peripheral
Supported Multi-rotor
 Quad-rotor: I4, X4
 Hexa-rotor: I6, V6, Y6, IY6
 Octo-rotor: X8, I8, V8
Supported ESC output
400Hz refresh frequency.
Supported Transmitter for Built-in Receiver
Futaba FASST (MULT, MLT2, 7CH) Series and DJI DESST Series
External Receiver Supported
Futaba S-Bus, DSM2, PPM
Recommended Battery
2S ~ 6S LiPo
Other DJI Products Supported
Z15, iOSD Mark II, D-BUS Adapter, S800 EVO, 2.4G Data Link,
H3-2D
Electrical & Mechanical
Power Consumption
MAX 5W (Typical Value: 0.3A@12.5V）
Operating Temperature
-5°C to +60°C
Total Weight
<= 224g (overall)
Dimensions
 MC: 54mm x 39mm x 14.9mm
 IMU: 41.3mm x 30.5mm x 26.3mm
 GPS-COMPASS PRO: 62 mm (diameter) x 14.3 mm
 PMU: 39.5mm×27.6mm×9.8mm
 LED-BTU-I：30mm x 30mm x 7.9mm
Flight Performance (can be effected by mechanical performance and payloads)
Hovering Accuracy (In GPS ATTI. Mode)
 Vertical: ± 0.5m
 Horizontal: ± 1.5m
Maximum Wind Resistance
<8m/s (17.9mph / 28.8km/h)
Max Yaw Angular Velocity
150deg/s
Max Tilt Angle
35°
Ascent / Descent
6m/s
