dji A2 - Settings of Gain Values for Your Reference; The Transmitter Setup of Futaba

©2013 DJI Innovations. All Rights Reserved 42 |
Gear
Channe 8 (AUX4)
2-Position switch, e.g. SF
H3-2D
Channe 12（AUX5）
Knob switch, e.g. LD、RD
Settings of gain values for Your Reference
To set the value of basic gain and attitude gain you can refer to the following diagram. These values are only for
reference and may vary in practice.
The Transmitter setup of FUTABA
Please configure the Frequency item on your Transmitter adhere to the table below. (The names of FASST modes
here are based to the Transmitter FUTABA T8FG, please ensure to select the most similar mode as the names
differs for different Transmitters)
Transmitter type
AREA
FASST
FUTABA 18MZ
Default
FASST-MULTI\FASST-7CH
FUTABA 14MZ with TM-14
Default
MULT\7CH
FUTABA 14SG
FRANCE\GENERAL
FASST-MULTI\FASST-7CH
FUTABA 12Z 2.4G FASST with TM-14
Default
MULT\7CH
FUTABA 12FG 2.4G FASST with TM-14
Default
MULT\7CH
FUTABA 10CG or 10C with TM-10
Default
7CH
FUTABA 9C SUPER with TM-7 or TM-8
Default
7CH
FUTABA 8FG SUPER
FRANCE\GENERAL
MLT2\MULT\7CH
FUTABA 8FG
FRANCE\GENERAL
MULT/7CH
FUTABA 7C 2.4G
Default
Default
FUTABA 6EX FASST
Default
Default
Aircraft
Configuration Information
Basic
Attitude
Motor
ESC
Propeller
Battery
Weight
Pitch
Roll
Yaw
Pitch
Roll
Vertical
F450
DJI-2212
DJI-30A
DJI-8 Inch
3S-2200
890 g
150
150
135
150
150
140
F550
DJI-2212
DJI-30A
DJI-8 Inch
4S-3300
1530 g
170
170
150
160
160
150
S800 EVO+Z15
DJI-4114
DJI-40A
DJI-15Inch
6S-15000
7000g
140
140
130
140
140
130
